This article introduces the setting method of "image file metadata", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set image file metadata?
- Where is the image file metadata configuration barcode?
- How to adjust image file metadata parameters?
Resolution / Answer
This setting controls the device's sound, lighting, aiming, or image-related feedback. It is usually used when you need to reduce the beep sound, confirm the scanning status, improve lighting positioning, or adjust the image reading effect.
When enabled, transferred JPEG format images are accompanied by the following EXIF 2.2 standard data fields:
- Time (since power on)
- Sensors used
-Device name
- Manufacturer
- Frame rate
- Host type
- Image number (since power on)
- Image enhancement parameter settings
- Image edge sharpening parameter settings
- Image contrast enhancement parameter settings
This parameter has no effect on images in TIFF or BMP format.
Enable image file metadata (01h)
Scan the following barcode to enable image file metadata (01h).
* Disable image file metadata (00h)
Scan the following barcode, * Image file metadata is disabled (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
