This article introduces the setting method of "Image Rotation", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set image rotation?
- Where is the image rotation configuration barcode?
- How to adjust image rotation parameters?
Resolution / Answer
This setting controls the device's sound, lighting, aiming, or image-related feedback. It is usually used when you need to reduce the beep sound, confirm the scanning status, improve lighting positioning, or adjust the image reading effect.
This parameter controls image rotation by 0°, 90°, 180°, or 270°.
* Rotate 0° (00h)
Scan the following barcode, * Rotate 0° (00h).
Rotate 90° (01h)
Scan the following barcode and rotate 90° (01h).
Rotate 180° (02h)
Scan the following barcode and rotate 180° (02h).
Rotate 270° (03h)
Scan the following barcode to rotate 270° (03h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
