This article introduces the setting method of "Video Resolution", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set video resolution?
- Where is the video resolution configuration barcode?
- How to adjust the video resolution parameters?
Resolution / Answer
This article introduces the use and configuration method of "Video Resolution". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
This parameter changes the video resolution before transmission. The rows and columns are removed from the image, resulting in a smaller video image with the original content but at a lower resolution.
Optional values:
Resolution value Video image size
Full resolution 752 × 480
1/2 376 × 240
1/4 188 × 120
Full resolution (00h)
Scan the following barcode, at full resolution (00h).
1/2 resolution (01h)
Scan the following barcode, 1/2 resolution (01h).
* 1/4 resolution (03h)
Scan the following barcode, *1/4 resolution (03h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
