This article is used to troubleshoot issues related to "USB device type" and provides corresponding processing directions and settings.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- What about USB device types?
- What is the reason for the USB device type?
- How to deal with USB device types?
- What settings need to be checked for the USB device type?
Resolution / Answer
This article is used to explain the meaning and common processing directions of phenomena such as "USB device type". Usually when the scan results are abnormal, the device behavior is not as expected, or you need to check whether the current parameters are set incorrectly, you can refer to this article to check them one by one.
Select the desired USB device type.
Note: After changing the USB device type, the decoder automatically resets and emits the standard power-on beep sequence.
Note: Before selecting a USB CDC host, please install the CDC INF file on the host first to ensure that the decoder does not stall due to USB enumeration failure when powered on. If the decoder stalls, follow these steps to resume:
1) Install CDC INF file; or
2) After powering on, press and hold the trigger for 10 seconds to power up the decoder in the backup USB configuration; after powering on, scan for other "USB device types".
* Symbol Native API (SNAPI) with image interface
Scan the following barcode, * Symbol Native API with Imaging Interface (SNAPI).
Symbol Native API without image interface (SNAPI)
Scan the following barcode, Symbol Native API without Imaging Interface (SNAPI).
HID keyboard emulation
Scan the following barcode for HID keyboard emulation.
IBM Desktop USB
Scan the following barcode, IBM Desktop USB.
IBM Handheld USB
Scan the following barcode for IBM Handheld USB.
USB OPOS Handheld
Scan the following barcode, USB OPOS Handheld.
Simple COM port emulation
Scan the following barcode for simple COM port emulation.
USB CDC Host
Scan the following barcode for the USB CDC host.
SSI over USB CDC
Scan the following barcode, SSI over USB CDC.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
