This article introduces the setting method of "Target Video Frame Size", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set target video frame size?
- Where is the target video frame size configuration barcode?
- How to adjust the target video frame size parameter?
Resolution / Answer
This article introduces the use and configuration method of "Target Video Frame Size". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
Select the number of 100-byte blocks to transfer per second. The smaller the value, the more frames are transmitted per second but the video quality is reduced; the larger the value, the better the video quality but the slower the transmission.
To set the target video frame size, scan the barcode below, then scan the 3-digit numeric barcode from Appendix D, "Numeric Barcodes," corresponding to the number of 100-byte blocks in the range 800-20,000 bytes. For example, select 1500 bytes to scan 0, 1, and 5; select 900 bytes to scan 0, 0, and 9. Default 2200 bytes.
Target video frame size
Scan the following barcode for the target video frame size.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
