This article introduces the setting method of "Video Viewfinder Image Size", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set video viewfinder image size?
- Where is the video viewfinder image size configuration barcode?
- How to adjust the video viewfinder image size parameters?
Resolution / Answer
This setting controls the device's sound, lighting, aiming, or image-related feedback. It is usually used when you need to reduce the beep sound, confirm the scanning status, improve lighting positioning, or adjust the image reading effect.
Select the number of 100-byte blocks. Range 800-12,000 bytes. The smaller the value, the more frames are transmitted per second; the larger the value, the better the video quality.
To set the video viewfinder image size, scan the barcode below, then scan the 3-digit numeric barcode from Appendix D, "Numeric Barcodes," corresponding to the number of 100-byte blocks in the range 800-12,000 bytes. For example, select 1500 bytes to scan 0, 1, and 5; select 900 bytes to scan 0, 0, and 9. Default 1700 bytes.
Video viewfinder image size
Scan the following barcode for the video viewfinder image size.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
