This article is used to troubleshoot issues related to "USB National Keyboard Type" and provides corresponding processing directions and settings.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- What about USB country keyboard types?
- What is the reason for the USB country keyboard type?
- How to deal with the USB national keyboard type?
- What settings need to be checked for USB country keyboard type?
Resolution / Answer
This article is used to explain the meaning and common processing directions of phenomena such as "USB country keyboard type". Usually when the scan results are abnormal, the device behavior is not as expected, or you need to check whether the current parameters are set incorrectly, you can refer to this article to check them one by one.
Scan the barcode corresponding to the keyboard type. This setting only takes effect for USB HID keyboard emulation devices.
NOTE: After changing the USB country keyboard type, the decoder automatically resets and emits the standard power-on beep sequence.
* North American Standard USB Keyboard
Scan the following barcode,* North American Standard USB Keyboard.
German Windows
Scan the following barcode, German Windows.
French Windows
Scan the following barcode, French Windows.
Canadian French Windows 95/98
Scan the following barcode, Canadian French Windows 95/98.
Canadian French Windows 2000/XP
Scan the following barcode, Canadian French Windows 2000/XP.
Belgian French Windows
Scan the following barcode, Belgian French Windows.
Spanish Windows
Scan the following barcode for Spanish Windows.
Italian Windows
Scan the following barcode to configure Italian Windows.
Swedish Windows
Scan the following barcode, Swedish Windows.
UK English Windows
Scan the following barcode, UK English Windows.
Japanese Windows (ASCII)
Scan the following barcode, Japanese Windows (ASCII).
Brazilian Portuguese Windows
Scan the following barcode, Brazilian Portuguese Windows.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
