This article is used to troubleshoot issues related to "USB CAPS Lock coverage" and provides corresponding processing directions and settings.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- What to do if USB CAPS Lock is overwritten?
- What is the reason for USB CAPS Lock overwriting?
- How to deal with USB CAPS Lock overwriting?
- What settings need to be checked for USB CAPS Lock override?
Resolution / Answer
This article is used to explain the meaning and common treatment directions of phenomena such as "USB CAPS Lock coverage". Usually when the scan results are abnormal, the device behavior is not as expected, or you need to check whether the current parameters are set incorrectly, you can refer to this article to check them one by one.
Only takes effect for HID keyboard emulation devices. Enable this to preserve the original capitalization of data regardless of the Caps Lock key state. This setting is always enabled for the Japanese Windows (ASCII) keyboard type and cannot be disabled.
Override Caps Lock key (enabled)
Scan the following barcode to override the Caps Lock key (enable).
* Do not override the Caps Lock key (disabled)
Scan the following barcode,* which does not cover the Caps Lock key (disabled).
Note: If "Simulate Caps Lock" and "Caps Lock Override" are enabled at the same time, "Caps Lock Override" takes precedence.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
