This article introduces the setting method of "Function Key Mapping", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set function key mapping?
- Where is the function key mapping configuration barcode?
- How to adjust function key mapping parameters?
Resolution / Answer
This article introduces the use and configuration method of "Function Key Mapping". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
Characters with ASCII values less than 32 are usually sent as control key sequences (see Table 8-2 on page 8-18). When this parameter is enabled, bolded entries in the table are sent instead of the standard mapping. Items without bold entries in the table remain unchanged regardless of whether this parameter is enabled.
* Disable function key mapping
Scan the following barcode to * disable function key mapping.
Enable function key mapping
Scan the following barcode to enable function key mapping.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
