This article introduces the setting method of "Serial Host Type", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set the serial host type?
- Where is the serial port host type configuration barcode?
- How to adjust the serial port host type parameters?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
To select the serial host interface, scan one of the following barcodes.
Note: Scanning "Standard RS-232" will activate the serial port driver, but will not change the port settings (such as parity, data bits, handshake). Scanning other host type barcodes will change these settings.
Standard RS-232
Scan the following barcode, standard RS-232.
ICL Serial
Scan the following barcode, ICL Serial.
Wincor-Nixdorf Serial Mode A
Scan the following barcode, Wincor-Nixdorf Serial Mode A.
Wincor-Nixdorf Serial Mode B
Scan the following barcode, Wincor-Nixdorf Serial Mode B.
Olivetti ORS4500
Scan the following barcode, Olivetti ORS4500.
Omron
Scan the following barcode, Omron.
OPOS/JPOS
Scan the following barcode, OPOS/JPOS.
Fujitsu Serial
Scan the following barcode, Fujitsu Serial.
CUTE¹
Scan the following barcode, CUTE¹.
¹ CUTE The host disables all parameter scanning (including "set defaults"). If CUTE is accidentally selected, scan "* Enable Parameter Scan (01h)" on page 6-6 before switching host selection.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
