This article introduces the setting method of "Baud Rate", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set the baud rate?
- Where is the baud rate configuration barcode?
- How to adjust the baud rate parameters?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
The baud rate is the number of data bits transmitted per second. Please set the baud rate of the decoder to be consistent with the host device, otherwise the data may not reach the host or may be distorted when it arrives.
* Baud rate 9600
Scan the following barcode, * Baud rate 9600.
Baud rate 19,200
Scan the following barcode, baud rate 19,200.
Baud rate 38,400
Scan the following barcode, baud rate 38,400.
Baud rate 57,600
Scan the following barcode, baud rate 57,600.
Baud rate 115,200
Scan the following barcode, baud rate 115,200.
Baud rate 230,400
Scan the following barcode, baud rate 230,400.
Baud rate 460,800
Scan the following barcode, baud rate 460,800.
Baud rate 921,600
Scan the following barcode, baud rate 921,600.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
