This article introduces the setting method of "stop bit", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set stop bit?
- Where is the stop bit configuration barcode?
- How to adjust the stop bit parameters?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
A stop bit at the end of each transmitted character marks the end of that character's transmission and prepares the receiving device to receive the next character in the serial data stream. Please select the number of stop digits (1 or 2) according to the settings of the receiving device.
* 1 stop bit
Scan the following barcode, * 1 stop.
2 stop bits
Scan the following barcode, 2 stops.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
