This article introduces the setting method of "Host Serial Port Response Timeout", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set the host serial port response timeout?
- Where is the host serial port response timeout configuration barcode?
- How to adjust the host serial port response timeout parameters?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
This parameter specifies how long the decoder waits for an ACK, NAK, or CTS before determining that a transmission error has occurred. Only takes effect in ACK/NAK software handshake mode or RTS/CTS hardware handshake mode.
* Minimum: 2 seconds
Scan the following barcode, *Minimum: 2 seconds.
Low: 2.5 seconds
Scan the following barcode, low: 2.5 seconds.
Medium: 5 seconds
Scan the following barcode, Medium: 5 seconds.
High: 7.5 seconds
Scan the following barcode, High: 7.5 seconds.
Max: 9.9 seconds
Scan the following barcode, Max: 9.9 seconds.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
