This article introduces the setting method of "parity check", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set parity?
- Where is the parity configuration barcode?
- How to adjust parity parameters?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
The parity bit is the highest bit of each ASCII-encoded character. Select the verification type according to the host device requirements:
- **Odd parity**: The parity bit is 0 or 1, so that the number of "1"s in the encoded characters is an odd number.
- **Even parity**: The check bit is 0 or 1, so that the number of "1"s in the encoded characters is an even number.
- **No Check**: Select this when parity check is not required.
Odd parity
Scan the following barcode to verify.
Even parity
Scan the following barcode to configure even check.
* None
Scan the following barcode, * None.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
