This article introduces the setting method of "data bit", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set data bits?
- Where is the data bit configuration barcode?
- How to adjust the data bit parameters?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
This parameter allows the decoder to interface with devices requiring 7-bit or 8-bit ASCII protocol.
7 digits
Please scan the appropriate 7-digit barcode below.
* 8 bits
Scan the following barcode, *8 digits.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
