This article introduces the setting method of "RTS line status", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set RTS line status?
- Where is the RTS line status configuration barcode?
- How to adjust RTS line status parameters?
Resolution / Answer
This article introduces the use and configuration method of "RTS line status". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
This parameter sets the idle state of the serial port host RTS line. Scan the barcode below to select the RTS line status as low or high.
* Host RTS low
Scan the following barcode, * Host RTS low.
Host RTS High
Scan the following barcode, host RTS is high.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
