This article introduces the setting method of "Ignore unknown characters", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up to ignore unknown characters?
- Where is the code to ignore unknown characters?
- How to adjust the ignore unknown characters parameter?
Resolution / Answer
This article introduces the purpose and configuration method of "Ignore unknown characters". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
"Unknown characters" refer to characters that are not recognized by the host computer. When "Send barcodes containing unknown characters" is selected, the decoder will send all barcode data except unknown characters without emitting an error beep; when "Do not send barcodes containing unknown characters" is selected, the decoder will only send the data before the first unknown character is encountered and emit an error beep.
* Send barcode (containing unknown characters)
Scan the following barcode to * send the barcode (contains unknown characters).
Do not send barcodes (containing unknown characters)
Scan the following barcode. No barcode (containing unknown characters) will be sent.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
