This article introduces the setting method of "Decoding UPC/EAN/JAN Additional Code", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up decoding UPC/EAN/JAN add-ons?
- Where is the decoding UPC/EAN/JAN add-on code setup code?
- How to adjust the decoding UPC/EAN/JAN additional code parameters?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
Additional codes are barcodes attached according to a specific format convention (such as UPC A+2, UPC E+2, EAN 13+2). The options are as follows:
- **Ignore UPC/EAN with appended codes (default)**: When the decoder sees a UPC/EAN symbol with appended codes, it only decodes the UPC/EAN part and ignores the appended characters.
- **Only decode UPC/EAN with additional characters**: The decoder only decodes UPC/EAN symbols with additional characters and ignores symbols without additional characters.
- **Automatically identify UPC/EAN additional codes**: The decoder immediately decodes UPC/EAN symbols with additional characters; if the symbol does not have additional codes, the barcode needs to be scanned again for the number of times set in "UPC/EAN/JAN Additional Code Redundancy" on page 11-16 before the data is transmitted to confirm that there is indeed no additional code.
- When any of the following **Additional Code Mode** is selected, the decoder immediately transmits the EAN-13 barcode starting with the prefix and with additional characters; if there is no additional code, the data must be scanned for the above redundancy times before transmitting the data. UPC/EAN barcodes that do not begin with this prefix are transmitted immediately:
- Enable 378/379 add-on code mode
- Enable 978/979 add-on code mode
- Enable 977 add-on code mode
- Enable 414/419/434/439 add-on code mode
- Enable 491 add-on code mode
- **Enable Smart Supplemental Mode**: Applicable to EAN-13 barcodes starting with any of the above prefixes.
- **User-defined additional code type 1**: Applicable to EAN-13 barcodes starting with a user-defined 3-digit prefix. Set this prefix in "User-defined add-on codes" on page 11-16.
- **User-Defined Extension Code Types 1 and 2**: Applicable to EAN-13 barcodes starting with one of two user-defined 3-digit prefixes. Set two prefixes in "User-defined additional codes" on page 11-16.
- **Smart add-on code + User-defined 1**: Applicable to EAN-13 barcodes starting with any of the above prefixes or user-defined 1 prefix.
- **Smart Append + User Defined 1 and 2**: Applicable to EAN-13 barcodes starting with any of the above prefixes or one of the two user defined prefixes.
NOTE: To minimize the risk of transmitting invalid data, explicitly select one of the "Decode" or "Ignore" additional characters.
Decode only UPC/EAN/JAN with add-on code (01h)
Scan the following barcode to decode only UPC/EAN/JAN with add-ons (01h).
* Ignore additional code (00h)
Scan the following barcode, * ignore the add-on code (00h).
Automatically determine UPC/EAN/JAN additional code (02h)
Scan the following barcode to automatically identify the UPC/EAN/JAN add-on code (02h).
Enable 378/379 add-on code mode (04h)
Scan the following barcode to enable 378/379 add-on mode (04h).
Enable 978/979 add-on code mode (05h)
Scan the following barcode to enable the 978/979 add-on code mode (05h).
Enable 977 add-on code mode (07h)
Scan the following barcode to enable the 977 add-on code mode (07h).
Enable 414/419/434/439 additional code mode (06h)
Scan the following barcode to enable the 414/419/434/439 add-on code mode (06h).
Enable 491 additional code mode (08h)
Scan the following barcode to enable 491 add-on mode (08h).
Enable smart additional code mode (03h)
Scan the following barcode to enable smart add-on mode (03h).
User-defined additional code type 1 (09h)
Scan the following barcode, User-Defined Add-On Code Type 1 (09h).
User-defined additional code types 1 and 2 (0Ah)
Scan the following barcode to configure User-defined add-on code types 1 and 2 (0Ah).
Smart add-on code + user-defined 1 (0Bh)
Scan the following barcode to configure smart add-on code + user-defined 1 (0Bh).
Smart add-on code + user-defined 1 and 2 (0Ch)
Scan the following barcode to configure Smart Add-on Code + User Defined 1 and 2 (0Ch).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
