This article introduces the setting method of "/Disable UPC-E1", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to enable/disable UPC-E1?
- How to turn off/disable UPC-E1?
- / Where is the switch setting to disable UPC-E1?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
UPC-E1 is disabled by default.
Note: UPC-E1 is not a UCC (Uniform Code Council) approved symbology.
Enable UPC-E1 (01h)
Scan the following barcode to enable UPC-E1 (01h).
* Disable UPC-E1 (00h)
Scan the following barcode, * Disable UPC-E1 (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
