This article introduces the setting method of "UPC/EAN/JAN additional code AIM ID format", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set the UPC/EAN/JAN add-on code AIM ID format?
- UPC/EAN/JAN add-on code Where is the AIM ID formatting code?
- How to adjust the UPC/EAN/JAN add-on code AIM ID format parameters?
Resolution / Answer
This setting is used to intercept, hide, insert, replace or format the scanned code data content. It is usually used when only part of the barcode content needs to be uploaded, useless characters need to be removed, or the business system requires a fixed data format.
When "Transmission Code ID Character" on page 6-28 is set to "AIM Code ID Character", select the output format when reporting UPC/EAN/JAN with additional codes:
- **Separate**: Use respective AIM IDs but transmit them once, that is: `]E<0 or 4><data>]E<1 or 2>[additional data]`
- **Combined**: Use one AIM ID for one-time transmission, that is: `]E3<data+additional data>`
- **Separate Transmissions**: Use respective AIM IDs and transmit separately, that is:
`]E<0 or 4><data>` `]E<1 or 2>[Additional data]`
Separate (00h)
Scan the following barcode, separated (00h).
* Merge (01h)
Scan the following barcode, * Merge (01h).
Separate transmission (02h)
Scan the following barcode to transmit separately (02h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
