This article introduces the setting method of "UPC-E1 Preamble", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set UPC-E1 preamble?
- Where is the UPC-E1 preamble configuration barcode?
- How to adjust UPC-E1 preamble parameters?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
Three options for transmitting the UPC-E1 preamble to the host: transmit system characters only, transmit system characters and country code ("0" for the United States), or do not transmit the preamble. Please select according to the host system.
No leader (<DATA>) (00h)
Scan the following barcode without the leading character (<DATA>) (00h).
* System characters (<system characters> <DATA>) (01h)
Scan the following barcode, * System Characters (<System Characters> <DATA>) (01h).
System characters and country code (<country code> <system character> <DATA>) (02h)
Scan the following barcode to configure system characters and country code (<country code> <system characters> <DATA>) (02h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
