This article introduces the setting method of "UCC Coupon Extension Code", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set UCC coupon extension code?
- Where is the UCC coupon extension code setup code?
- How to adjust the UCC coupon extension code parameters?
Resolution / Answer
This article introduces the use and configuration method of "UCC Coupon Extension Code". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
Enable this parameter to decode UPC-A barcodes starting with the digits "5", EAN-13 barcodes starting with "99", and UPC-A/GS1-128 coupon codes. To scan all types of coupon codes, UPC-A, EAN-13, and GS1-128 must be enabled together.
Enable UCC coupon extension code (01h)
Scan the following barcode to enable the UCC coupon extension code (01h).
* Disable UCC coupon extension code (00h)
Scan the following barcode, * Disabled UCC Coupon Extension Code (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
