This article introduces the setting method of "User-defined additional code", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set user-defined add-on codes?
- Where is the user-defined add-on code configuration barcode?
- How to adjust user-defined additional code parameters?
Resolution / Answer
This article introduces the purpose and configuration method of "User-defined add-on code". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
**Additional code 1: Parameter # F1h 43h**
**Additional code 2: Parameter # F1h 44h**
If the "User-Defined Add-On" option is selected in "Decoding UPC/EAN/JAN Add-Ons" on page 11-13, scan the "User-Defined Add-On 1" barcode to set the first 3-digit prefix, and then scan the 3-digit number using Appendix D "Numeric Barcodes." Scan "User Defined Extension Code 2" to set the second 3-digit prefix, then scan 3 more digits.
User-defined additional code 1
Scan the following barcode, User-Defined Add-on Code 1.
User-defined additional code 2
Scan the following barcode, User-Defined Add-on Code 2.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
