This article introduces the setting method of "EAN-8/JAN-8 Extension", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up EAN-8/JAN-8 extension?
- Where is the EAN-8/JAN-8 extended configuration code?
- How to adjust the EAN-8/JAN-8 extended parameters?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
Enabling this parameter prepends 5 leading zeroes to the decoded EAN-8 symbol, making its format compatible with EAN-13.
Disabling this option transmits EAN-8 symbols unchanged.
Enable EAN/JAN zero extension (01h)
Scan the following barcode to enable EAN/JAN zero extension (01h).
* Disable EAN/JAN zero extension (00h)
Scan the following barcode, * Disable EAN/JAN zero extension (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
