How to set up coupon reporting | M-4107 Type

Updated
This article introduces the setting method of "Coupon Report", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.

Applicable to:

CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U

Questions

  • How to set up coupon reporting?
  • Where is the coupon reporting configuration barcode?
  • How to adjust the coupon reporting parameters?

Resolution / Answer

This article introduces the use and configuration method of "Coupon Report". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.

Traditional coupon codes (legacy) consist of two barcode segments: UPC/EAN and Code 128. The new coupon code consists of a single GS1 DataBar Expanded barcode, and the new format supports higher purchase amounts (up to $999.99) and supports complex discount rules (such as secondary purchase conditions).

There is also a transitional coupon code that includes both UPC/EAN and GS1 DataBar Expanded to accommodate retailers who do not recognize the new coupon code as well as those who can handle the new coupon code.

Scan the barcode below and choose how to decode the coupon code:

  • **Old Coupon Symbols**: Scan the old version to report UPC and Code 128; scan the transitional version to only report UPC; scan the new version without decoding.
  • **New Coupon Symbols**: Scan the old version to report only UPC or Code 128; scan the transitional or new version to report GS1 DataBar Expanded.
  • **Two formats (Both)**: Scan the old version to report UPC and Code 128; scan the transitional or new version to report GS1 DataBar Expanded.

Old Coupon Code (00h)

Scan the following barcode, the old coupon code (00h).

Barcode

* New Coupon Code (01h)

Scan the following barcode,* New Coupon Code (01h).

Barcode

Two formats (02h)

Scan the following barcode, both formats (02h).

Barcode

If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
