This article introduces the setting method of "Code 93 length", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set Code 93 length?
- Where is the Code 93 length configuration barcode?
- How to adjust the length parameter of Code 93?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
The Code 93 length can be set to any length, one or two discrete lengths, or a length within a specified range (the meaning is the same as the previous Code 39 length setting).
- **Single Discrete Length**: Only decode Code 93 of the selected length.
- **Two Discrete Lengths**: Only decode Code 93 of one of the two selected lengths.
- **Length in range**: Decodes Code 93 whose length is within the specified range.
- **Any length**: Decode Code 93 of any length.
Code 93 - Single Discrete Length
Scan the following barcode, Code 93 - Single Discrete Length.
Code 93 - Two discrete lengths
Scan the following barcode, Code 93 - two discrete lengths.
* Code 93 - Length within range
Scan the following barcode, *Code 93 - Length Within Range.
Code 93 - Any length
Scan the following barcode, Code 93 - any length.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
