This article introduces the setting method of "Code 11 check digit verification", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up Code 11 check digit verification?
- Where is the Code 11 check digit verification configuration barcode?
- How to adjust the Code 11 check digit verification parameters?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
This feature allows the decoder to verify the integrity of all Code 11 symbols, ensuring that the data conforms to the specified check digit algorithm. You can choose "one-digit verification", "two-digit verification" or "disabled".
To enable this feature, scan the barcode below that corresponds to the check digits contained in the Code 11 symbol.
* Disabled (00h)
Scan the following barcode, * Disabled (00h).
One check digit (01h)
Scan the following barcode to configure one check digit (01h).
Two check digits (02h)
Scan the following barcode to configure two check digits (02h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
