This article introduces the setting method of "ISBT splicing", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up ISBT splicing?
- Where is the ISBT splicing configuration barcode?
- How to adjust ISBT splicing parameters?
Resolution / Answer
This article introduces the use and configuration method of "ISBT splicing". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
Select the splicing method of ISBT code pairs:
- **Disable ISBT splicing**: The decoder will not splice the ISBT code pairs encountered.
- **Enable ISBT splicing**: The decoder requires that two ISBT codes must appear to decode and splice, a single ISBT symbol will not be decoded.
- **Automatically identify ISBT splicing**: The decoder immediately decodes and splices the ISBT code pair; if there is only a single ISBT symbol, the symbol must be decoded the number of times set in "ISBT Splicing Redundancy" on page 11-30 before transmitting the data to confirm that there is indeed no second ISBT symbol.
* Disable ISBT splicing (00h)
Scan the following barcode, * ISBT splicing is disabled (00h).
Enable ISBT splicing (01h)
Scan the following barcode to enable ISBT stitching (01h).
Automatically identify ISBT splicing (02h)
Scan the following barcode to automatically identify ISBT splicing (02h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
