This article introduces the setting method of "Code 39 to Code 32", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up Code 39 to Code 32?
- Where is the code to convert Code 39 to Code 32?
- How to adjust the parameters when converting Code 39 to Code 32?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
Code 32 is a variation of Code 39 used by the Italian pharmaceutical industry. Scan the corresponding barcode below to enable or disable Code 39 to Code 32 conversion.
Note: Code 39 needs to be enabled first for this parameter to take effect.
Enable Code 39 to Code 32 (01h)
Scan the following barcode to enable Code 39 to Code 32 (01h).
* Disable Code 39 to Code 32 (00h)
Scan the following barcode, * disable Code 39 to Code 32 (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
