This article introduces the setting method of "Code 39 full ASCII conversion", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up Code 39 full ASCII conversion?
- Code 39 Where is the full ASCII conversion configuration barcode?
- How to adjust the full ASCII conversion parameters of Code 39?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
Code 39 Full ASCII is a variant of Code 39 that encodes the full ASCII character set through character pairing. Scan the corresponding barcode below to enable or disable.
Enable Code 39 Full ASCII (01h)
Scan the following barcode to enable Code 39 Full ASCII (01h).
* Disable Code 39 Full ASCII (00h)
Scan the following barcode, * Disable Code 39 Full ASCII (00h).
Note: Trioptic Code 39 and Code 39 Full ASCII cannot be enabled at the same time.
The correspondence between Code 39 Full ASCII and Full ASCII is related to the host. For details, see the ASCII character set table in the corresponding interface chapter (see page 8-18 USB ASCII character set or page 10-20 serial port ASCII character set).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
