This article introduces the setting method of "Code 11 length", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set Code 11 length?
- Where is the Code 11 length configuration barcode?
- How to adjust the length parameter of Code 11?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
Code 11 length can be set to any length, one or two discrete lengths, or within a specified range.
- **Single Discrete Length**: Only decode Code 11 of the selected length.
- **Two Discrete Lengths**: Only decode Code 11 of one of the two selected lengths.
- **Length in range**: Decodes Code 11 whose length is within the specified range.
- **Any length**: Decode Code 11 of any length.
Code 11 - Single Discrete Length
Scan the following barcode, Code 11 - Single Discrete Length.
Code 11 - Two discrete lengths
Scan the following barcode, Code 11 - two discrete lengths.
* Code 11 - Length within range
Scan the following barcode, *Code 11 - Length Within Range.
Code 11 - Any length
Scan the following barcode, Code 11 - any length.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
