This article introduces the setting method of "Transmission I 2 of 5 check digit", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set transmission I 2 of 5 check digit?
- Transmission I 2 of 5 Where is the check digit configuration barcode?
- How to adjust the transmission I 2 of 5 check digit parameters?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
Scan the corresponding barcode below to select whether to include the check bit when transmitting I 2 of 5 data.
Transmit I 2 of 5 Check Digit (Enabled) (01h)
Scan the following barcode to transmit the I 2 of 5 check digit (enabled) (01h).
* Do not transmit I 2 of 5 check digit (disabled) (00h)
Scan the following barcode, * The I 2 of 5 check digit is not transmitted (disabled) (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
