This article introduces the setting method of "I 2 of 5 length", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set I 2 of 5 length?
- Where is the I 2 of 5 length configuration barcode?
- How to adjust the length parameter of I 2 of 5?
Resolution / Answer
This article introduces the use and configuration method of "I 2 of 5 length". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
I 2 of 5 length range is 0-55. Can be set to any length, one or two discrete lengths, or a length within a specified range.
- **Single Discrete Length**: Only decode I 2 of 5 of the selected length.
- **Two Discrete Lengths**: Only decode I 2 of 5 for one of the two selected lengths.
- **Length in range**: Decodes I 2 of 5 whose length is within the specified range.
- **Any length**: Decode I 2 of 5 of any length.
Note: Due to the structural characteristics of the I 2 of 5 symbology, when the scan line only covers a part of the code, it may still be transmitted as a complete scan, resulting in the transmitted data being less than the data encoded by the barcode. To prevent this, the application should select "Single Discrete Length" or "Two Discrete Lengths".
* I 2 of 5 - single discrete length
Scan the following barcode, *I 2 of 5 - Single discrete length.
I 2 of 5 - two discrete lengths
Scan the following barcode, I 2 of 5 - two discrete lengths.
I 2 of 5 - length within range
Scan the following barcode, I 2 of 5 - Range Length.
I 2 of 5 - any length
Scan the following barcode, I 2 of 5 - any length.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
