This article introduces the setting method of "I 2 of 5 to EAN-13", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up I 2 of 5 to EAN-13?
- I 2 of 5 to where is the EAN-13 setup code?
- How to adjust the parameters of I 2 of 5 to EAN-13?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
Enabling this parameter converts the 14-character I 2 of 5 code to EAN-13 and transmits it to the host in EAN-13 form. Prerequisites are that I 2 of 5 must be enabled and the code must start with zero and have a valid EAN-13 check digit.
I 2 of 5 to EAN-13 (enabled) (01h)
Scan the following barcode, I 2 of 5 to EAN-13 (Enabled) (01h).
* Do not convert I 2 of 5 to EAN-13 (disabled) (00h)
Scan the following barcode, * does not convert I 2 of 5 to EAN-13 (disabled) (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
