This article introduces the setting method of "MSI check digit", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set MSI check digit?
- Where is the MSI check digit configuration barcode?
- How to adjust the MSI check digit parameters?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
MSI symbols must contain a check digit and are always verified by the reader. The second check digit is optional. If the MSI code contains two check digits, scan "Two MSI Check Digits" to enable verification of the second check digit.
See "MSI Check Digit Algorithm" on page 11-57 for algorithm selection for the second bit.
* One MSI check digit (00h)
Scan the following barcode, * one MSI check digit (00h).
Two MSI check digits (01h)
Scan the following barcode, two MSI check digits (01h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
