This article introduces the setting method of "MSI check digit algorithm", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set the MSI check digit algorithm?
- Where is the MSI check digit algorithm configuration barcode?
- How to adjust the MSI check digit algorithm parameters?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
There are two algorithms for verification of the second MSI check digit. Please scan the barcode below that corresponds to the algorithm used.
MOD 10 / MOD 11(00h)
Scan the following barcode, MOD 10 / MOD 11 (00h).
* MOD 10 / MOD 10(01h)
Scan the following barcode, * MOD 10 / MOD 10 (01h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
