This article introduces the setting method of "/Disable Matrix 2 of 5", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to enable/disable Matrix 2 of 5?
- How to turn off/disable Matrix 2 of 5?
- / Where is the switch setting to disable Matrix 2 of 5?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
Enable Matrix 2 of 5 (01h)
Scan the following barcode to enable Matrix 2 of 5 (01h).
* Disable Matrix 2 of 5 (00h)
Scan the following barcode, * Disabled Matrix 2 of 5 (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
