This article introduces the setting method of "Matrix 2 of 5 check digit", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set Matrix 2 of 5 check digit?
- Where is the Matrix 2 of 5 check digit configuration barcode?
- How to adjust the check digit parameters of Matrix 2 of 5?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
The check digit is the last character of the code symbol and is used to verify data integrity. Scan the appropriate barcode below to enable or disable Matrix 2 of 5 check digit verification.
Enable Matrix 2 of 5 check digit (01h)
Scan the following barcode to enable the Matrix 2 of 5 check digit (01h).
* Disable Matrix 2 of 5 check digit (00h)
Scan the following barcode, * to disable the Matrix 2 of 5 check digit (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
