This article introduces the setting method of "Transmitting Matrix 2 of 5 check digits", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set transmission Matrix 2 of 5 check digit?
- Where is the transmission Matrix 2 of 5 check digit configuration barcode?
- How to adjust the check digit parameters of the transmission Matrix 2 of 5?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
Transmit Matrix 2 of 5 check digit (01h)
Scan the following barcode to transmit the Matrix 2 of 5 check digit (01h).
* Do not transmit Matrix 2 of 5 check digit (00h)
Scan the following barcode, * The Matrix 2 of 5 check digit (00h) is not transmitted.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
