This article introduces the setting method of "D 2 of 5 length", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set D 2 of 5 length?
- Where is the D 2 of 5 length configuration barcode?
- How to adjust the length parameter of D 2 of 5?
Resolution / Answer
This article introduces the use and configuration method of "D 2 of 5 length". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
D 2 of 5 Length range 0-55. Can be set to any length, one or two discrete lengths, or a length within a specified range.
- **Single discrete length**, **Two discrete lengths**, **Length within range**, **Any length** - the meaning is the same as before.
Note: Due to the structural characteristics of the D 2 of 5 symbology, when the scan line only covers a part of the code, it may still be transmitted as a complete scan, resulting in the transmitted data being less than the data encoded by the barcode. To prevent this, the application should select "Single Discrete Length" or "Two Discrete Lengths".
* D 2 of 5 - single discrete length
Scan the following barcode, * D 2 of 5 - Single discrete length.
D 2 of 5 - two discrete lengths
Scan the following barcode, D 2 of 5 - two discrete lengths.
D 2 of 5 - length within range
Scan the following barcode, D 2 of 5 - Range Length.
D 2 of 5 - any length
Scan the following barcode, D 2 of 5 - any length.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
