This article introduces the setting method of "Matrix 2 of 5 length", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set the Matrix 2 of 5 length?
- Where is the Matrix 2 of 5 length configuration barcode?
- How to adjust the length parameter of Matrix 2 of 5?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
The Matrix 2 of 5 length can be set to any length, one or two discrete lengths, or a length within a specified range (the meaning is the same as the previous Code 39 length setting).
* Matrix 2 of 5 - single discrete length
Scan the following barcode, * Matrix 2 of 5 - Single discrete length.
Matrix 2 of 5 - two discrete lengths
Scan the following barcode, Matrix 2 of 5 - two discrete lengths.
Matrix 2 of 5 - Length within range
Scan the following barcode, Matrix 2 of 5 - Range Length.
Matrix 2 of 5 - any length
Scan the following barcode, Matrix 2 of 5 - any length.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
