This article introduces the setting method of "Australia Post Format", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to format Australia Post?
- Where are the Australia Post formatting codes?
- How to adjust Australia Post format parameters?
Resolution / Answer
This setting is used to intercept, hide, insert, replace or format the scanned code data content. It is usually used when only part of the barcode content needs to be uploaded, useless characters need to be removed, or the business system requires a fixed data format.
Scan the appropriate barcode below to select one of Australia Post's formats:
- **Automatic Determination (Smart Mode)**: Try to decode the "Customer Information Field" using N encoding table and C encoding table.
Note: This option increases the risk of misdecoding because the encoding table used is not specified in the encoded data format.
- **Original format**: Output the original barcode pattern as a string of numbers between 0-3.
- **Alphanumeric Encoding**: Decode the "Customer Information Field" using the C encoding table.
- **Numeric Encoding**: Decode "Customer Information Field" using N encoding table.
Further information on Australia Post's encoding tables can be found in the Australia Post Customer Barcode Technical Specifications available at http://www.auspost.com.au.
* Automatic identification (00h)
Scan the following barcode to configure * automatically determined (00h).
Original format (01h)
Scan the following barcode, in original format (01h).
Alphanumeric coding (02h)
Scan the following barcode to configure alphanumeric code (02h).
Numeric code (03h)
Scan the following barcode to configure numerically coded (03h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
