This article introduces the setting method of "GS1 DataBar Limited Security Level", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set the security level of GS1 DataBar Limited?
- Where is the GS1 DataBar Limited security level configuration barcode?
- How to adjust the security level parameters of GS1 DataBar Limited?
Resolution / Answer
This setting is used to control the additional characters and output mode at the end of the scanned data or during the output process. It is usually used when you need to automatically wrap lines, jump to the next input box, or adjust the data output format after scanning the QR code.
For GS1 DataBar Limited barcodes, the decoder provides four levels of decoding security. Security is inversely proportional to decoding aggressiveness. The higher the security level, the more conservative the scan will be, so please only select the necessary security level.
- **Level 1**: No white margins required. This level complies with the original GS1 standard, but scanning certain UPC symbols beginning with "9" or "7" may mistakenly identify them as DataBar Limited.
- **Level 2**: Automatic risk detection. Certain UPC symbols may still be misread as DataBar Limited when scanning. If a misread is detected, the decoder switches to Level 3 or Level 1.
- **Level 3**: Complies with GS1's new proposed standard requiring 5X trailing margin.
- Level 4**: Exceeds GS1 standard requirements; requires 5X front and rear margins.
Security level 1 (01h)
Scan the following barcode, Security Level 1 (01h).
Security Level 2 (02h)
Scan the following barcode, Security Level 2 (02h).
* Security Level 3 (03h)
Scan the following barcode, * Security Level 3 (03h).
Security Level 4 (04h)
Scan the following barcode, Security Level 4 (04h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
