This article introduces the setting method of "Data Matrix", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up Data Matrix?
- Where is the Data Matrix setup code?
- How to adjust Data Matrix parameters?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
* Enable Data Matrix (01h)
Scan the following barcode to * enable Data Matrix (01h).
Disable Data Matrix (00h)
Scan the following barcode to disable the Data Matrix (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
