This article introduces the setting method of "GS1 DataBar Expanded", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up GS1 DataBar Expanded?
- Where is the GS1 DataBar Expanded setup code?
- How to adjust the parameters of GS1 DataBar Expanded?
Resolution / Answer
This setting is used to control the additional characters and output mode at the end of the scanned data or during the output process. It is usually used when you need to automatically wrap lines, jump to the next input box, or adjust the data output format after scanning the QR code.
- GS1 DataBar Expanded
- GS1 DataBar Expanded Stacked
* Enable GS1 DataBar Expanded (01h)
Scan the following barcode to* enable GS1 DataBar Expanded (01h).
Disable GS1 DataBar Expanded (00h)
Scan the following barcode to disable GS1 DataBar Expanded (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
