This article introduces the setting method of "GS1 DataBar to UPC/EAN", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up GS1 DataBar to UPC/EAN?
- Where is the GS1 DataBar to UPC/EAN configuration barcode?
- How to adjust the parameters of converting GS1 DataBar to UPC/EAN?
Resolution / Answer
This setting is used to control the additional characters and output mode at the end of the scanned data or during the output process. It is usually used when you need to automatically wrap lines, jump to the next input box, or adjust the data output format after scanning the QR code.
This parameter only applies to GS1 DataBar and GS1 DataBar Limited symbols that are not decoded as part of a composite code. When enabled, DataBar and DataBar Limited symbols with a leading "0" will have the leading "010" removed and reported as EAN-13.
For barcodes starting with two or more "0"s but not all 6 "0"s, this parameter will remove the leading "0100" and report it in UPC-A form. The "UPC-A Preamble" parameter (used to transmit system characters and country codes) also applies to converted barcodes. Note: System characters and check digits will not be removed.
Enable GS1 DataBar to UPC/EAN (01h)
Scan the following barcode to enable GS1 DataBar to UPC/EAN (01h).
* Disable GS1 DataBar to UPC/EAN (00h)
Scan the following barcode, * Disable GS1 DataBar to UPC/EAN (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
