This article introduces the setting method of "UPC composite mode", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up UPC composite mode?
- Where is the UPC Composite Mode Setup Code?
- How to adjust UPC composite mode parameters?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
If Composite CC-A/B (page 11-74) is enabled, you can select how UPC symbols are joined to 2D symbols during transmission:
- **UPC NEVER CONNECT**: Transmit UPC barcodes regardless of whether a 2D symbol is detected.
- **UPC Always Concatenated**: Transmits UPC barcode and 2D part; if 2D is not detected, UPC barcode is not transmitted.
- **Automatic detection of UPC composite**: The decoder determines whether a 2D part is present and then transmits the UPC and, if present, the 2D part.
UPC Never Connect (00h)
Scan the following barcode, UPC Never Connect (00h).
* UPC always linked (01h)
Scan the following barcode, *UPC always concatenated (01h).
Automatically identify UPC composite (02h)
Scan the following barcode to automatically identify UPC composite (02h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
