This article introduces the setting method of "Decode Data Matrix Image", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up decoding Data Matrix image?
- Where is the decoded Data Matrix image setup code?
- How to adjust the decoding Data Matrix image parameters?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
Decoding method for mirrored Data Matrix barcodes:
- **Always**: Only decode mirrored Data Matrix barcodes.
- **Never**: Do not decode mirrored Data Matrix barcodes.
- **Auto**: Decode non-mirrored and mirrored Data Matrix barcodes at the same time.
Never (00h)
Scan the following barcode, never (00h).
Always (01h)
Scan the following barcode, always (01h).
* Automatic (02h)
Scan the following barcode, * Automatic (02h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
