This article introduces the setting method of "redundancy level 4", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up redundancy level 4?
- Where is the redundancy level 4 setup code?
- How to adjust redundancy level 4 parameters?
Resolution / Answer
This article introduces the purpose and configuration method of "redundancy level 4". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
The following symbology must be read successfully 3 times before it can be decoded:
Table 11-5 Redundancy level 4 symbology
Symbology Code length
All All
* Redundancy level 1 (01h)
Scan the following barcode, * Redundancy Level 1 (01h).
Redundancy Level 2 (02h)
Scan the following barcode, Redundancy Level 2 (02h).
Redundancy Level 3 (03h)
Scan the following barcode, Redundancy Level 3 (03h).
Redundancy Level 4 (04h)
Scan the following barcode, Redundancy Level 4 (04h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
