This article introduces the setting method of "Intercharacter Gap Size", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set the Intercharacter Gap Size?
- Where is the Intercharacter Gap Size configuration barcode?
- How to adjust the Intercharacter Gap Size parameter?
Resolution / Answer
This article introduces the use and configuration method of "Intercharacter Gap Size". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
The character separation between Code 39 and Codabar is usually very small. Due to different barcode printing processes, this interval may exceed the maximum allowed value, causing the decoder to be unable to decode the symbol. If this occurs, scan the "Large Character Spacing" parameter to tolerate these non-compliant barcodes.
* Normal character interval (06h)
Scan the following barcode, * normal character spacing (06h).
Large character interval (0Ah)
Scan the following barcode to configure large character spacing (0Ah).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
